920x-ET

MTL Instruments GmbH

Details

These rugged, 5 to 9 port DIN-rail and panel mount Ethernet switches are designed for use in harsh and hazardous environments. The full range is ATEX certified for Zone 2 and UL approved for Class 1, Division 2 hazardous areas.

- High performance at the lowest cost
- Plug and play functionality - works out of the box
- 10/100BaseT(X) via RJ45 and 100BaseFX via optical fibre
- Excellent cost/performance ratio
- Supports temperatures ranging from -40 to 85°C
- Redundant dual DC power inputs
- Up to 3 fibre optic ports for noise immune links

Produktbeschreibung

Produktname
920x-ET
Produkttyp
Industrial Ethernet Switch
Produkteinführung
2011
Maße (BxHxT)
27,1/40,7 x 119,4 x 97 mm
Gehäusematerial
Aluminium
Montage
Hutschiene, Wandauch in Ex-Zone 2
Spannungsversorgung
10-30Vdc
Gehäuseschutzart (IP xx)
IP30
Betriebstemperatur von
-10 °C
Betriebstemperatur bis
60 °C
Lüfterloser Betrieb
Anzeige für Geräte- und Netzwerkstatus
LEDs: zwei je Netzanschluss und Stromversorgung
Zulassungen
UL508/CSA C22.2/14; EN61010-1,CE; FCC part 15, ICES-003; EN6100-6-4, CE; IEC61000-6-2, CE; UL1604, CSA C22.2/213; EN60079-15 (Zone 2; Category 3); IEC60825-1, Class 1; FDA 21 CFR 1040.10 and 1040.11

Einsatz im Ethernet-Netzwerk

Unmanaged Ethernet Switch
Managed Ethernet Switch
Portanzahl für 10/100Base-TX
4, 5, 8
Portanzahl für 10/100Base-FX
0, 1, 3
Konfigurieren
Web-, Telnet-, CLI-Interface

Firma

MTL Instruments GmbH
